2SC2690A (Pack of 10)

Summary of the Product These items, which are general-purpose transistors, are intended for use in radio frequency and audio power amplifiers. FEATURES ? Suitable for usage in output stage of TV vertical deflection circuit and driver stage of 50 to 100 W audio amplifiers. ? High voltage and high frequency (fT) VCEO = 120 V/2SC2690A; fT = 175 MHz; VCE = 5.0 V; IC = 0.2 A) ? Similar to the PNP transistors 2SA1220 and 2SA1220A. Additional information related to the Product 160 V is the collector to base voltage. 160 V from the collector to the emitter Voltage from Emitter to Base: 5.0 V DC Collector Current: 1.2 A 2.5 A is the collector current (pulse). DC Base Current: 0.3 A Total Power Dissipation – 1.2 W (T A = 25?C) 20 W is the total power dissipation at 25 ?C. 150 ?C for the junction temperature Temperature Range (T) for Storage: 55 to 150 ?C
